    SHINOVA
    YX932D
    Suction Unit
    Get Latest Price!
    1 Pieces
    Within 15 days against payment
    T/T, L/C, Paypal, Cash, Other
    Cat, Dog, Horse, Cow
    Operating Room, ICU Room

Descriptions

Model YX932D Electric Suction Unit, intended for extracting various mucus such as purulence, blood and phlegm from body cavity or wound in hospitals or center of social medical service, is a mobile suction unit with a high flow, high vacuum and a novel style. It can satisfy most demands in operating rooms.

1. An oil-less vacuum pump, double piston cylinder with a high flow, high vacuum, the pump needs maintenance free.
2. Move smoothly and freely with a swing-type pull handle; the accessory-case for placing foot-switch and power supply wire makes it convenient for movement or storage.
3. Large-bore and large capacity bottles with stopper having sealing ring, easy to clean and to open or close.
4. The overflow protection device is intended to prevent liquid or solid particles form entering the intermediate tubing and pump.
5. Transparent non-toxic PVC hoses and unique connections are easy to observe and link.
6. The level of vacuum required in clinic can be controlled by adjusting the regulator knob, and a synchronized indication on the vacuum meter.
7. Stability and durability, low noise, safe and reliable to operate.


Specifications

Max vacuum: ≥0.09MPa (680mmHg)
Adjustable vacuum range: 0.02MPa(150mmHg)~Max.
Flow rate: ≥32L/Min
Noise: ≤60dB(A)
Storage bottles: 2500ML×2
Power supply: AC220V/50Hz (110V customized)
Input power: 150VA
G.W./N.W.: 14/12kg

Packing dimension: 40cm×38cm×47cm
