Descriptions
A) Advanced Detection Technology
• Laser flow cytometry for accurate leukocyte differentiation
• Combined impedance method and colorimetry detection
• Improved precision compared to traditional methods
B) Reticulocyte Analysis Function
• Provides RET#, RET%, and IRF values
• Supports evaluation of bone marrow function
• Assists in diagnosis and classification of anemia
C) Multi-Parameter Testing Capability
• Total 37 parameters including:
– 25 routine parameters
– 6 research parameters
– 3 reticulocyte parameters
• Includes RBC & PLT histograms and WBC scatterplots
• Provides comprehensive diagnostic data for veterinarians
D) Multi-Species & Flexible Modes
• Supports multiple animal species including dogs, cats, horses, cattle, pigs, and more
• Whole blood, pre-diluted, and reticulocyte testing modes
• Dedicated feline testing mode for improved accuracy
E) Efficient Workflow & Data Management
• Throughput up to 60 samples per hour
• Large storage capacity up to 200,000 results
• 10.4-inch touchscreen for intuitive operation
• USB interfaces for data export and system connectivity
F) Clinical & Research Applications
Suitable for:
• Veterinary clinics and animal hospitals
• Diagnostic laboratories
• Veterinary universities and research institutes
Common Applications:
• Complete blood count (CBC) analysis
• Anemia diagnosis and monitoring
• Infection and inflammation assessment
• Hematology research studies
Specifications
Application: Veterinary Laboratory / Animal Hospital / Research Institute
Test Parameters: 5-Part Differential + RET (37 Parameters)
Throughput: Up to 60 Samples/Hour
Sample Volume: Whole Blood ≤15µL / Prediluted ≤20µL
Display: 10.4-inch Touch Screen
Data Storage: Up to 200,000 Results
Interface: 4 × USB Ports
Species: Multi-species (Dog, Cat, Horse, Cow, etc.)
Working Environment: 15°C–35°C / 20%–85% RH
Power Supply: AC Power
Warranty: 1 Year
Configurations
Standard Configuration
• Hematology Analyzer Main Unit ×1
• Power Cable ×1
• User Manual ×1
