Descriptions

High-definition CMOS camera captures high quality endoscopy images.
Field of view technology provides excellent and detailed images.
Large range angulations make it easier to observation.
3-100mm depth of view provides precise observation ability for both close and far objects.
Various working channel makes it easier to pass through all kind of instruments for animal treatment.
12-inch LCD monitor provides a level of mobility that the endoscope is operated indoors or outdoors (optional).
Video processor is updatable to form multifunctional endoscopy examinations such as gastroscopy, laparoscopy, bronchoscopy, etc.
Wider clinical applications for gastroscopy, colonoscopy and bronchoscopy in small animals like dogs and cats, and for gastroscopy, colonoscopy, bronchoscopy, esophagoscopy, hysteroscopy, rhinoscopy, pharynogoscopy and laryngoscopy in large animals like horses and cattle.

Specifications

Endoscopes

Model	Insertion Tube Diameter	Working Length	Working Channel Diameter	Field of View	Depth of Field	Tip Bending	Application
VE-8015	8.3mm	1500mm	2.8mm	120°	3-100mm	210°(U), 90° (D) 100°(R), 100°(L)	Dog, cat, pig, sheep, etc. (2kg~80kg)
VE-6012	6.3mm	1200mm	2.0mm	120°	3-100mm	210°(U), 90° (D) 100°(R), 100°(L)	Small dog, cat, monkey, rabbit, etc.  (0.6kg~30kg)
VE-1233	12.9mm	3300mm	3.7mm	120°	3-100mm	180°(U), 180°(D) 160°(R), 160°(L)	Large animal horse, dolphin, etc. (≥80kg)
VE-3006	3.0mm	600mm	1.2mm	120°	3-100mm	180°(U), 180°(D)	Dog, cat, pig, sheep, etc.

Video Processor

Model	VIS-300	VIS-300M	VIS-310
Application	2-in-1 (Gastroscopy/Laparoscopy)	2-in-1 (Gastroscopy/Laparoscopy)	3-in-1 (Gastroscopy/Laparoscopy/Bronchoscopy)
Extra Monitor	/	12-inch LCD monitor	/
Light Source	40W LED
Luminance	≥1000Lm
Service Life	≥20,000hours
Air Pressure	0.05MPa
Flow Rate	0.75M³/N
White Balance	Automatic
Recording	64G TF card for photo/video
Imaging Output	HDMI/DVI, 1080P
Voltage	100-240V, 50-60Hz

Configurations

Standard Configuration:
Veterinary endoscope, video processor with light source, accessories: biopsy forceps*1pc, foreign body forceps*1pc, cleaning brush*1pc, leakage tester*1pc, venting cap*1pc, water bottle*1pc, TF card & card reader*1pc, HDMI cable*1pc, DVI cable*1pc, power cord*1pc, carrying case*1pc, etc.

Optional:
Video processor with light source VIS-300M or VIS-310, 19" LCD medical monitor, CO₂ insufflator, laparoscope kit, trolley, etc.
