Descriptions
A) Portable Veterinary Imaging Solution
• Lightweight handheld X-ray generator
• Designed for clinic and field applications
• Setup time less than 1 minute
• Suitable for mobile veterinary services and farm visits
B) High-Quality Diagnostic Images
• 75kV output improves image penetration
• 0.4mm focal spot for sharp image detail
• Reduced motion blur through shorter exposure times
• Supports examination of chest, limbs, skull, spine, and other anatomical regions
C) Wireless Workflow
• Wireless image transmission
• Wireless exposure switch operation
• Compatible with laptop-based imaging workflow
• Improves examination efficiency and mobility
D) Advanced Flat Panel Detector
• 17 × 17 inch wireless detector
• CsI scintillator technology
• 3072 × 3072 pixel resolution
• 139μm pixel size
• 16-bit A/D conversion for detailed image presentation
E) Safety and Efficiency
• Low-dose imaging design
• Reduced radiation exposure for operators and patients
• Fast image acquisition within seconds
• Rechargeable battery supports approximately 200 exposures per charge
F) Clinical Applications
Suitable for:
• Companion animal hospitals
• Equine veterinary practices
• Farm animal examinations
• Emergency veterinary services
• Mobile veterinary imaging
• Orthopedic and diagnostic imaging procedures
Specifications
Application: Veterinary Hospital / Animal Clinic / Mobile Veterinary Service
Imaging Technology: Digital Radiography (DR)
Detector Size: 17 × 17 Inch Flat Panel Detector
X-Ray Generator Type: Portable Handheld Generator
Output Power: 560W
Tube Voltage: 40–75kV
Tube Current: 2–8mA
Connectivity: Wireless
Power Supply: 100–240V AC
Warranty: 1 Year
Configurations
Standard Configuration
• DR-15V Handheld X-Ray Generator ×1
• 17 × 17 Inch Wireless Flat Panel Detector ×1
• Veterinary Imaging Software ×1
• Wireless Exposure Switch ×1
• Battery Charger ×1
• Power Adapter ×1
• User Manual ×1
Optional Configuration
• Mobile Detector Stand
• Detector Rack
• Imaging Workstation Laptop
• Protective Carrying Case
