Descriptions
A) Advanced Digital Imaging Platform
Full digital beam former with digital dynamic focusing
Digital variable aperture and dynamic apodizer
64 A/D sampling channels for receiving and transmitting channels
High-density probes with wider frequency bands for optimized near-field and far-field imaging
ePure speckle reduction, eFCI frequency compounding and eSCI spatial compounding technologies
B) Veterinary-Specific Diagnostic Functions
Professional veterinary software packages for different pets
Professional veterinary body chart
Animal-specific measurement software package
Professional veterinary examination settings
Patient information management system
Comprehensive diagnostic report
C) Dual-Screen Clinical Operation
21.5-inch medical-grade adjustable HD color monitor
13.3-inch touchscreen with tilt adjustment up to 45°
Monitor resolution of 1920 × 1080
Ergonomic silicon keyboard design
Adjustable monitor and arm positioning for convenient operation
D) Comprehensive Imaging Modes
B, 2B, 4B, M and B/M imaging
Color Doppler, Power Doppler and Triplex imaging
PW, HPRF and Continuous Wave Doppler
3D/4D imaging
Pulse Inversion Harmonic Imaging
Anatomical M Mode and Tissue Specific Imaging
eView panoramic imaging and trapezoidal imaging
Auto EF and Auto IMT calculation
E) Flexible Probe Configuration
Four active probe connectors with automatic probe recognition
Standard micro convex probe for abdominal and general examinations
Standard linear probe for superficial and vascular examinations
Optional convex, micro convex, high-frequency linear, intraoperative, rectal linear and phased array probes
Optional CW modules for phased array probes
Specifications
Application: Veterinary Imaging / Animal Hospital / Veterinary Clinic
Animal Type: Dogs, Cats, Horses, Cattle, Sheep, Pigs and Other Animals
System Type: Trolley Veterinary Color Doppler Ultrasound System
Main Monitor: 21.5-inch Medical Grade Adjustable HD Color Monitor
Touchscreen: 13.3-inch Touchscreen
Monitor Resolution: 1920 × 1080
Probe Connectors: 4
Storage: 512GB SSD
Imaging Modes: B, 2B, 4B, M, B/M, CFM, PW, PDI, Triplex, CW, 3D/4D
Standard Probes: Micro Convex 5.0–10.0MHz + Linear 5.0–14.0MHz
Veterinary Software: Animal-Specific Measurement / Body Chart / Veterinary Settings
Report: Comprehensive Diagnostic Report
Patient Management: Patient Information Management System
Configurations
Main Unit with 21.5-inch Medical Grade Monitor + 13.3-inch Touchscreen ×1
Micro Convex Probe 65C15N, 5.0–10.0MHz ×1
Linear Probe 75L40N, 5.0–14.0MHz ×1Optional Configuration:
Convex Probe 35C50N, 2.0–6.0MHz
Micro Convex Probe 35C20H, 2.5–5.0MHz
Small Footprint Linear Probe 10L25J, 5.0–14.0MHz
High Frequency Linear Probe 18L13N, 11.0–25.0MHz
Intraoperative Probe 10L25NL, 5.0–14.0MHz
Rectal Linear Probe 55L60H, 5.0–12.0MHz
Phased Array Probe 30P16N + CW Module, 2.0–5.0MHz
High Frequency Phased Array Probe 50P10N + CW Module, 3.0–8.0MHz
23.8-inch High Resolution Medical Monitor
Micro Convex Probe with OPU System
Footswitch
ECG Module
DICOM 3.0
Biopsy Guides for Convex Probe
Biopsy Guides for Linear Probe
