Descriptions
A) Full HD Imaging System
• 1920×1080 Full HD resolution with 60 fps real-time imaging
• High-performance CMOS sensor for clear and detailed visualization
• Minimum illumination: 3.0 Lux
• Image enhancement and color adjustment functions
B) Intelligent Control & Operation
• Camera handle with 4 shortcut buttons:
– White balance
– Image capture
– Video recording
– Freeze function
• One-touch automatic white balance and backlight compensation
• Easy operation for efficient surgical workflow
C) Recording & Storage System
• Full HD video recording and playback
• Supports external USB storage up to 1TB
• Recording format: H.264 (1080P60)
• Image format: JPEG / MP4
• Multiple control methods: handle, remote control, and main unit
D) LED Cold Light Source & Display
• LED light source power: 30W
• Illumination up to 700,000 Lux
• Color temperature: 5000K–7000K
• Long lifespan: ≥20,000 hours
• 27-inch medical monitor with high brightness (1000 cd/m²)
• Wide viewing angle: 178° × 178°
E) Medical Trolley System
• Steel frame with aluminum alloy structure
• Adjustable height and rotating arm design
• Equipped with shelves, drawers, cable management system, and casters
• Suitable for 26–32 inch monitors
F) Clinical Applications & Instruments
Suitable for:
• Veterinary laparoscopy surgery
• Minimally invasive procedures
• ENT and general endoscopy
• Diagnostic and surgical applications
Standard laparoscopic instrument kit (LapKit-A1):
• 0° laparoscope (Φ5mm)
• Trocars (threaded & non-threaded)
• Grasping forceps / biopsy forceps
• Insufflation needle
• Sterilization containers
Optional Equipment:
• Electrosurgical Unit (ESU)
• Vessel Sealing Generator
• Ultrasonic Scalpel
• CO₂ Insufflator
Specifications
Application: Veterinary Surgery / Animal Hospital / Veterinary Clinic
Imaging Resolution: Full HD 1920×1080
Frame Rate: 60 fps
Camera Type: CMOS Endoscopy Camera
Light Source: LED Cold Light Source
Monitor: 27-inch Medical Display (Optional 24")
Storage: USB External Storage up to 1TB
Recording Format: H.264 / MP4 / JPEG
Output Interface: HDMI / DVI (Optional SDI)
Control Method: Camera Handle / Remote / Panel Control
Cart System: Medical Trolley with Adjustable Structure
Optional Equipment: ESU / Vessel Sealer / Ultrasonic Scalpel / Insufflator
OEM/ODM: Available
Warranty: 1 Year
Configurations
Standard Configuration
1. Integrator
2. Camera head
3. Coupler
4. Manual
5. USB disk
6. Engineer controller
7. DVI to DVI
8. Power cord*2
9. Cold Light Source System Main Unit
10.Light Guide Cable
11. Light Guide Connector
