Descriptions
A) Electric Optical Magnification
Electric continuous zoom with a 1:6 ratio
4X–24X main microscope magnification
Φ11–Φ68mm field of view
10X/22B eyepieces with 45° visual angle
B) Independent Assistant Microscope
Three-step drum wheel magnification
6X, 10X, and 16X magnification
Assistant microscope positioned at 90° to the main microscope
12.5X/18B assistant eyepieces
C) Flexible Microscope Frame
Gas spring balanced frame
Foot-controlled X-Y movement with 40mm travel
Motorized fine focusing with 40mm adjustment range
Vertical adjustment range of 850–1350mm
Cross arm maximum spread radius of 1200mm
D) Coaxial Cold Light Illumination
Dual independent halogen light source
Coaxial cold light source with fiber optic illumination
Illuminance of ≥80,000LX
15V/150W light bulbs
Retinal protection devices included
E) Expandable Imaging Options
Optional independent LED illumination
LED illuminance of ≥160,000LX
LED service life of more than 30,000 hours
Optional HD digital camera system
Optional optical adapter, Sony SLR camera, and 1920×1080P HD monitor
Specifications
Application: Ophthalmic Surgery / Veterinary Surgery
Product Type: Ophthalmic Operating Microscope
Main Microscope Magnification: 4X–24X
Zoom: Electric Continuous Zoom, 1:6
Field of View: Φ11–Φ68mm
Working Distance: 200mm
Eyepiece: 10X/22B
Eyepiece Visual Angle: 45°
PD Adjustment: 55–75mm
Assistant Microscope Magnification: 6X, 10X, 16X
Frame Type: Gas Spring Balanced Frame
Fine Focusing Range: 40mm
Illumination: Dual Independent Halogen Light Source
Illuminance: ≥80,000LX
Light Source: Coaxial Cold Light Source Fiber Optic Illumination
Configurations
Standard Configuration:
EOM-600 Main Microscope ×1
Assistant Microscope ×1
Gas Spring Balanced Frame ×1
Multifunctional Pedal ×1
Touch LCD Control Screen ×1
Dual Independent Halogen Light Source ×1
Coaxial Cold Light Source Fiber Optic Illumination ×1
Optional Configuration:
Independent LED Illumination System
Optical Adapter
Sony SLR Camera
1920×1080P HD Monitor
