    SHINOVA
    DS-0810
    Veterinary Bone Drill & Saw
    Get Latest Price!
    T/T, L/C, Paypal, Cash, Other

Descriptions

TPLO surgery (Tibial-Plateau-Leveling Osteotomy) is performed on dogs to stabilize the stifle joint after ruptures of the cranial cruciate ligament.


Features:

1) High-strength stainless steel shell to ensure the intraoperative safety for dogs.

2) Blade thickness and a variety of common knee prosthesis to match with the template, forming an osteotomy is perfect fit prosthesis, it brings you more accurate and rapid surgical procedures.

3) Specially designed saw tooth ensures very small contact pressure to achieve accurate and neat osteotomy, so it greatly reduces the generated heating when cutting that possibly leads to the risk of osteonecrosis.


Specifications

Frequency

0-16000Hz

Swing angle

11.5°

5-minute temperature

≤25

Noise

≤75dB

Sterilization temperature

≤135

Operation voltage

12V

Battery type

NI-MH Battery

Battery Voltage

9.6V~14.4V

Charging time

2 hours

Discharge time/1A

30min

Charger input voltage

AC 100-240V, 50/60Hz

Charger output power

7.2V-16.8V

Net weight

1.5KG


Configurations

Main engine*1pc

Saw blade*1pc (R10/R12/R15/R18/R20/R24/R27/R30mm, choose one of them)

Charger*1pc

Batteries*2pcs

Battery sterilization channels*2pcs

Internal hexagon spanner *1pc

Carrying case*1pc
