Descriptions
Portable design – 3.5 inches LCD Monitor:
Portable veterinary endoscope adopts the expanded viewing and recording capability. It enables observation
without cables or peripherals, providing with a level of mobility that allows it be operated almost anywhere.
Excellent optical system:
High definition image: High-definition CMOS camera adopts the 990K pixels. It can capture high quality images.
Wider field of view technology can provide excellent and detailed images.
Large range angulations make it easier to observation.
3-100mm depth of view provides precise observation ability for both close and far objects.
Wider instrument channel:
It is easier to operate that a wide range of instruments can be used with the 1.5mm~3.7mm diameter channel.
Specifications
Model
Diameter of Insertion Tube
Working Channel
Working Length
View Angle
View Depth
Range of Bending
Gastrix 35V
3.5mm
1.5 mm
600 mm
120°
3-50 mm
160° (U), 130° (D)
Gastrix 60V
5.8mm
2.0mm
1500 mm
120°
3-60 mm
180°(U),160°(D)
Gastrix 85V
8.5mm
2.0mm
1500 mm
120°
3-100mm
210°(U),90°(D),
100°(R),100°(L)
Gastrix 92V
9.0mm
2.8mm
3000 mm
140°
3-100mm
210°(U),90°(D),
100°(R),100°(L)
Colonix 98V
9.6mm
2.8mm
1500 mm
140°
3-100mm
210°(U),90°(D),
100°(R),100°(L)
Colonix 135V
12.8mm
3.7mm
3500 mm
140°
3~100mm
180°(U),180°(D),
160°(R),160°(L)
