Descriptions
A) Pregnancy Detection & Reproductive Applications
• Designed for livestock pregnancy diagnosis
• Supports bovine, ovine, swine, and equine reproduction analysis
• Built-in obstetric measurement packages:
– Bovine: BPD, TD, CRL
– Swine: GSD, LOIN
– Ovine: BPD, TD, CRL
– Equine: BPD, CRL, GSD
• Enables fast and accurate gestation evaluation
B) Imaging System & Modes
• B, 2B, 4B, B/M, and M display modes
• 256 grey scale imaging for clear visualization
• 24 pseudo color options for enhanced image contrast
• 4-section electronic focus with adjustable position
• Image optimization, edge enhancement, and dynamic range control
C) Probe Compatibility & Flexibility
Supports multiple probe types for different applications:
• Convex probe (3.5 MHz) for abdominal scanning
• Micro-convex probe (5.0 MHz)
• Rectal linear probe (6.5 MHz) for reproductive exams
• Linear probe (7.5 MHz) for soft tissue imaging
• Backfat probe for livestock measurement
D) Portable Design & Field Use
• Handheld structure for easy operation
• Lightweight and suitable for farm environments
• Built-in 2600mAh battery with ≥3 hours working time
• Shoulder strap and aluminum carrying case included
E) Data Storage & Workflow
• 32GB internal storage for images and data
• 255-frame cine loop playback
• Frame-by-frame and continuous playback modes
• One-click parameter reset for quick operation
F) User Interface & Connectivity
• 5.6-inch LED medical display
• Multi-language system (English standard)
• USB interface for data export
• Simple and intuitive control interface
Specifications
Application: Livestock Farm / Veterinary Clinic / Breeding Center
Animal Types: Cattle, Sheep, Pigs, Horses, Dogs, Cats
Usage: Pregnancy Detection / Reproductive Examination
Display: 5.6-inch LED Medical Display
Scan Mode: Convex / Linear / Rectal Probes
Display Modes: B / 2B / 4B / B/M / M
Storage: 32GB Internal Storage
Cine Loop: 255 Frames
Battery: 2600mAh Rechargeable Lithium Battery
Working Time: ≥3 Hours
Language: English / Chinese (Optional Multi-language)
Interface: USB / Charging Port / Probe Connector
OEM/ODM: Available
Warranty: 1 Year
Configurations
Standard Configuration
• Main Unit (with battery) ×1
• Probe ×1
• Power Adapter ×1
• Shoulder Strap ×1
• Aluminum Carrying Case ×1
• User Manual ×1
Optional Probes
• Convex Probe
• Micro-convex Probe
• Rectal Linear Probe
• Linear Probe
• Backfat Probe
