Descriptions

Application

1.Industrial use such as welding,glass cutting.

2.Fish farming, aquaculture

3.Oxygen supply for ozone generator

4.Oxygen cylinder filling system

Specifications

Model	SOC-15	SOC-20	SOC-30	SOC-40	SOC-60
Flow Rate	0-15LPM	0-20LPM	0-30LPM	0-40LPM	0-60LPM
Purity	93%(+3%)
Outlet Pressure	0.04-0.07MPA(6-10PSI)
Sound Level	≤60db
Power Consumption	≤850W	≤1100W	1650W	2200W	3300W
LCD Display	Switch times, operating pressure, present working time, accumulated working time
Net Weight	90Kgs	95Kgs	140Kgs	160Kgs	245Kgs
Alarm	Low purity alarm ,High&low pressure alarm, Power failure alarm
Size(mm)	680x500x1580	680x500x1580	860x630x1580	860x630x1580	860x630x2120
