Descriptions
High-definition CMOS camera captures high quality endoscopy images and mucosa details.
Field of view technology provides excellent and detailed images.
Large range angulations make it easier to observation.
3-100mm depth of view provides precise observation ability for both close and far objects.
Various working channel makes it easier to pass through all kind of instruments for animal treatment.
Control handle with four-direction, air-water valve, suction valve and capture/video functions.
Video processor is updatable to form multifunctional endoscopy examinations of gastroscopy, bronchoscopy or laparoscopy.
Patient’s information management to provide the edit and display on the monitor.
Support to expand to optical rigid endoscope camera system.
Wider clinical applications for gastroscopy, colonoscopy and bronchoscopy in small animals like dogs, cats or exotic animals, and for gastroscopy, colonoscopy, bronchoscopy, esophagoscopy, hysteroscopy, rhinoscopy, pharynogoscopy and laryngoscopy in large animals like horses, cows or dolphins.
Specifications
Application: For Gastroscopy (Connect 1500mm, 1200mm or 3300mm flexible endoscopes)
Color Adjustment: AWB R/G/B
Vessel Enhancement: OK
Enhancement Level: H/M/L
Iris: AVE/PEAK
Gamma Level: 1-15
Gain Level: 1-15
USB Memory: Record/Capture
Video Output: DVI/HDMI
Light Source: 80W LED
CRI: 90
Color Temperature: 5600k
Service Life: 25,000hours
Air Pressure: 0.05MPa
Air Level: H/M/L
Voltage: 100-240V, 50-60Hz
Configurations
Standard Configuration:
Veterinary endoscope, VIS-500 video processor and extension unit, accessories: biopsy forceps*1pc, grasping forceps*1pc, cleaning brush*1pc, leakage tester*1pc, Water-resistant cap*1pc, water bottle*1pc, HDMI cable*1pc, DVI cable*1pc, power cord*1pc, carrying case*1pc, etc.
Optional:
Video processor VIS-500B or VIS-500R, 19” LCD medical monitor, HD camera head, laparoscope kit, CO2 insufflator, trolley, reusable grasping forceps, reusable biopsy forceps, etc.
