Descriptions

4-inch high-definition image processor with multi-function of display, recording, storage and light source
High-resolution CMOS sensor performs clear image, real-time display and no transfer delay
Durable LED light source

Specifications

Model	Diameter of Insertion Tube	Working Channel	Working Length	View Angle	View Depth	Range of Bending
MiniScope 2P (HD 720P)	2.8 mm	1.2 mm	610 mm	120°	3-100 mm	180° (U), 130° (D) 120° (R), 120° (L)
MiniScope 3P (HD 720P)	3.8 mm	1.5 mm	1000 mm	120°	3-100 mm	180° (U), 130° (D) 120° (R), 120° (L)
MiniScope 5HP (HD 720P)	5.8 mm	2.8 mm	1500 mm	120°	3-100 mm	180° (U), 130° (D) 120° (R), 120° (L)

Image Processor

Screen size: 4-inch

Touch screen: Capacitive touch screen

Resolution: 720*720

Input interface: 20P

Standard voltage: DC3.6V

Power supply: Rechargeable lithium battery

Placement mode: Handheld, screen can be rotated

Operating time: Continuous operation time is not less than 60min with fully charged battery

Storage space: External memory card, with the maximum identifiable capacity of 128G

Dimension: 100mm*88mm*66mm

Weight: 225g
