Descriptions
Compact and save the space.Light and easy to moveAutomatically calculation by weight to the other parametersWith breathing mode PCV mode, achieve the breathing automaticallyAssure the animal more comfortableWith big animal bellow and small animal bellowGas source pipeline take the high precious gas source, no leakage foreverHD TFT Touch screen to make operation easy and simpleBuilt-in battery to support more than two hours in case of power failureMatching with different brands of veterinary anesthesia machine
Specifications
Display
9-inch TFT touch screen
Gas type
O2 or Air
Inlet pressure
280-600 kPa
Max flow
≤ 120 L / min
Operating Mode
VCV, PCV, SPONT, Manual, Demo
Waveform:
Pressure, Flow-rate, Volume
Loop
PV loop, PF loop, FV loop
Safety Pressure
System pressure does not exceed 6 KPa
Battery Type
Li-ion, work time more than 2 hours
Tidal volume Range
20 - 1500ml
Respiratory rate Range
1 ~ 150 bpm
Inspiratory time Range
0.1 ~ 12s
Breathing ratio Range
9.9:1 to 1:9.9
Percentage of inspiratory pause Range
0 to 50%
PEEP Range
OFF, 3 ~ 20 cmH2O
Support Pressure Range
0 ~ 60 cmH2O
Inspiratory Pressure Range
2 ~ 60 cmH2O
Flow trigger Range
0.5 ~ 20L/min
Pressure Trigger Range
-1 ~ -20 cmH2O
PSV Insp Termination Level
25%
Monitoring parameters
Inspiratory/Expiratory tidal volume Range:0 ~ 2500 mL
Minute ventilation
Display Range: 0 ~ 99L/min, Using Range: 0 ~ 25L/min
Spontaneous minute ventilation
Display Range: 0 ~ 99L/min, Using Range: 0 ~ 25L/min
Pea/Mean airway pressure Range
0 ~ 80 cmH2O
FiO2(optional) Range
15 to 100%
